Actually I am not familiar with the CLI configuration.
Below is my setting. How can I change?
!! Configuration of AP7532 version 5.9.0.0-033R
!
!
version 2.5
!
!
client-identity-group default
load default-fingerprints
!
ip access-list BROADCAST-MULTICAST-CONTROL
permit tcp any any rule-precedence 10 rule-description "permit all TCP traffic"
permit udp any eq 67 any eq dhcpc rule-precedence 11 rule-description "permit DHCP replies"
deny udp any range 137 138 any range 137 138 rule-precedence 20 rule-description "deny windows netbios"
deny ip any 224.0.0.0/4 rule-precedence 21 rule-description "deny IP multicast"
deny ip any host 255.255.255.255 rule-precedence 22 rule-description "deny IP local broadcast"
permit ip any any rule-precedence 100 rule-description "permit all IP traffic"
!
mac access-list PERMIT-ARP-AND-IPv4
permit any any type ip rule-precedence 10 rule-description "permit all IPv4 traffic"
permit any any type arp rule-precedence 20 rule-description "permit all ARP traffic"
!
ip snmp-access-list default
permit any
!
firewall-policy default
no ip dos tcp-sequence-past-window
no stateful-packet-inspection-l2
ip tcp adjust-mss 1400
!
!
mint-policy global-default
!
meshpoint-qos-policy default
!
wlan-qos-policy "Guest WiFi"
classification voice
classification non-wmm voice
voice-prioritization
svp-prioritization
rate-limit client to-air
rate-limit client to-air rate 3600
rate-limit client from-air
rate-limit client from-air rate 3600
qos trust dscp
qos trust wmm
!
wlan-qos-policy "Home WiFi"
classification voice
classification non-wmm voice
voice-prioritization
svp-prioritization
rate-limit client to-air rate 5000
rate-limit client from-air rate 5000
qos trust dscp
qos trust wmm
!
wlan-qos-policy default
qos trust dscp
qos trust wmm
!
radio-qos-policy default
!
roaming-assist-policy "Guest WiFi"
!
roaming-assist-policy "Home WiFi"
!
wlan "Guest WiFi"
ssid Guest
vlan 1
bridging-mode local
encryption-type ccmp
authentication-type none
no client-client-communication
fast-bss-transition
wpa-wpa2 psk 0 1234567890
use wlan-qos-policy "Guest WiFi"
use roaming-assist-policy "Guest WiFi"
!
wlan "Home WiFi"
ssid WiFi
vlan 1
bridging-mode local
encryption-type ccmp
authentication-type none
no client-client-communication
fast-bss-transition
wpa-wpa2 psk 0 wudi228920
use wlan-qos-policy "Home WiFi"
use roaming-assist-policy "Home WiFi"
!
smart-rf-policy default
assignable-power 5GHz max 20
assignable-power 5GHz min 20
assignable-power 2.4GHz max 20
assignable-power 2.4GHz min 20
channel-list 5GHz 21,25,36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132,136,140,149,153,157,161,165,184,188,192,196,208,212,216
channel-list 2.4GHz 1,2,3,4,5,6,7,8,9,10,11,12,13
channel-width 5GHz 80MHz
channel-width 2.4GHz auto
no smart-ocs-monitoring voice-aware 5GHz
no smart-ocs-monitoring voice-aware 2.4GHz
!
radius-group Guest
guest
policy vlan 1
policy ssid Guest
!
radius-group Home
policy vlan 1
policy ssid WiFi
!
radius-server-policy WERSP
use radius-group Home
use radius-group Guest
!
!
management-policy default
telnet
no http server
https server
ssh
user admin password 1 f9f3daa83b041b6be29a0e4b7b4a9836e7569af3cb2eaa8ea91a80f6813f9427 role superuser access all
snmp-server community 0 private rw
snmp-server community 0 public ro
snmp-server user snmptrap v3 encrypted des auth md5 0 admin123
snmp-server user snmpmanager v3 encrypted des auth md5 0 admin123
!
nsight-policy default
!
profile ap7532 default-ap7532
autoinstall configuration
autoinstall firmware
use radius-server-policy WERSP
crypto ikev1 policy ikev1-default
isakmp-proposal default encryption aes-256 group 2 hash sha
crypto ikev2 policy ikev2-default
isakmp-proposal default encryption aes-256 group 2 hash sha
crypto ipsec transform-set default esp-aes-256 esp-sha-hmac
crypto ikev1 remote-vpn
crypto ikev2 remote-vpn
crypto auto-ipsec-secure
crypto load-management
crypto remote-vpn-client
interface radio1
power 23
wlan "Home WiFi" bss 1 primary
wlan "Guest WiFi" bss 2 primary
interface radio2
power 23
wlan "Home WiFi" bss 1 primary
wlan "Guest WiFi" bss 2 primary
interface ge1
interface vlan1
ip address dhcp
ip address zeroconf secondary
ip dhcp client request options all
interface pppoe1
use firewall-policy default
use client-identity-group default
logging on
service pm sys-restart
router ospf
dpi
adoption-mode controller
!
rf-domain default
timezone Asia/Shanghai
country-code us
use smart-rf-policy default
use nsight-policy default
!
self
! ap7532 74-67-F7-01-24-FC
radio-count 2
use profile default-ap7532
use rf-domain default
hostname ap7532-0124FC
license AP VIRTUAL_CONTROLLER_DEFAULT_AP_LICENSE
no adoption-site
location default
interface radio1
data-rates default
ntp server 202.120.2.101
no virtual-controller
rf-domain-manager capable
no adoption-mode
!
!
end
